SPEKTRAs acoustic calibration systems CS18 are used for manufacturer-independent calibration of acoustic sensors, measurement microphones, sound level meters and other sound measuring systems.

The CS18 FF was developed as a compact system for calibration in the acoustic freefield. The anechoic calibration chamber can be set up in a normal quiet room of a building without any structural modifications. Therefore, it also offers smaller calibration laboratories a cost-effective way to offer free-field calibrations in an interesting frequency range.

A pressure comparison calibration for pressure microphones is possible with the CS18 SPL. The possibilities of both systems can be combined in the CS18 FF/SPL.

All systems can also be upgraded for electrical calibration of signal conditioners, such as microphone amplifiers (measurement microphone or IEPE types).


SPEKTRA-CS18-FF
CS18 FF
Secondary calibration of measuring microphones, sound level meters and other acoustic sensors according to IEC 61094-8 and IEC 61672

Download: SPEKTRA-CS18 Datasheet

Product Details:

  • frequency range 125 Hz … 20 kHz
  • calibration of microphones according to DIN EN 61094-8
  • calibration of sound level meters according to DIN EN 61672
  • periodic tests of sound level meters according to DIN EN 61672-3 (incl. electrical tests)
  • calibration of calibrators according to DIN EN 60942
  • compact anechoic chamber (can be installed in any room without construction work)

SPEKTRA-CS18-SPL
CS18 SPL
Pressure chamber secondary calibration of measuring microphones acc. to IEC 61094-5

Download: SPEKTRA CS18 SPLDatasheet

Product Details:

  • frequency range 31,5 Hz … 16 kHz
  • pressure chamber calibration of microphones according to DIN EN 61094-5
  • pressure chamber calibration of sound level meters according to DIN EN 61672
  • calibration of calibrators and pistonphones according to DIN EN 60942
  • can be combined with anechoic chamber (upgrade free field calibration)

SPEKTRA-CS18-SPL-VLF
CS18 SPL-VLF
Pressure chamber secondary calibration of measuring microphones and microphone measuring chains

Product Details:

  • frequency range 0,1 Hz … 31,5 Hz
  • pressure chamber calibration in the infrasound range
  • device under test is completely embedded in the pressure chamber
  • very good measurement uncertainty

Download: SPEKTRA CS18 SPL VLF Datasheet


Interesting Facts:

In its standard configuration, every CS18 calibration system is optimized for a specific practical application. Its performance, however, can be extended by means of optional extras. On customer’s demand, dedicated options can be compiled and offered with the system.

Download: Overview of CS18 optional extras (PDF)


Your Benefits:

With the CS18 Calibration system, SPEKTRA provides a means to cope with all requirements of traceable calibration and efficient laboratory operation in conformance with all applicable standards.

  • Complete turn-key calibration system
  • Including: Initial tracing to standard by traceable calibration of each supplied system in the SPEKTRA DAkkS Laboratory
  • Modular structure allows calibration with respect to several measurands by means of one system (acceleration, sound pressure, dynamic pressure, …)
  • Hardware interfaces for the calibration of sensors with digital interfaces (DTI, I2C, CAN,…)
  • Software interfaces for data exchange with instrumentation data bases, ERP systems, …
  • Systems are available for primary as well as secondary calibration
